8500 Deluxe Radius RV Sliding Windows
If you're looking for replacement options for the 8500 Series window, please contact us and provide the part number.
CLICK HERE For an example of the needed part number.
![]()
.jpg)
Deluxe Radius RV Sliding Window Features:
Large mounting flange for easy installation for easy installation with clamp ring
Heavy duty aluminum construction
Available in black or white frame finish
Only available in clamp ring mount, painted to match the frame
Safety glass standard in clear, light grey, dark grey or obscure
Radius Corners 3"
Sliding section has a frame around the glass
Picture window does not have weep holes
Removable fiberglass screen included
Window is 1/4" smaller than rough hole size
Stopped sill/stepped sill
All windows available in Full Egress depending on size
Minimum height for full egress 22"H; Maximum for full egress 35"H x 48"W
14 Business days before ready to ship out
***Looking from the outside of your unit, the arrow shows which direction the window would slide.
***If the window is a passenger/driver slider the window would slide forward to the front of the coach as to not open when in motion.
***Pricing based on current part number, non-current part numbers will be subject to additional setup fee***
